Waring 503527 CB15V, CB15VP ONE GALLON BLENDER VARIABLE SPEED CONTROL
MODULEUSD $459.00
Condition : New
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
* GENUINE OEM FACTORY ORIGINAL REPLACEMENT CONTROL PANEL AND CIRCUIT BOARD ASSEMBLY
* FOR USE ON ALL WARING CB15 SERIES ONE GALLON 3 SPEED BLENDERS WITH PULSE FEATURE PRODUCED AFTER AUGUST 20, 2013
* SIMPLE 5 WIRE LEAD CONNECTION AS FOLLOWS;
FROM 08/20/2013 TO 11/10/2017 PRODUCTION SPEED CONTROL RIBBON CONNECTOR TO C10 CONNECTOR, FROM LEFT TO RIGHT GREEN, RED, BLACK
BLACK MOTOR LEAD TO M+ CONNECTOR
BLUE MOTOR LEAD TO M- CONNECTOR
BROWN CORD POWER LEAD TO ACL (LINE) CONNECTOR
BLUE CORD POWER LEAD TO ACN (NEUTRAL) CONNECTOR
FROM POST 11/10/2017 PRODUCTION ON SPEED CONTROL RIBBON CONNECTOR TO C10 CONNECTOR, FROM LEFT TO RIGHT GREEN, RED, BLACK
BLACK MOTOR LEAD TO M+ CONNECTOR
RED MOTOR LEAD TO M- CONNECTOR
BROWN CORD POWER LEAD TO ACL (LINE) CONNECTOR
BLUE CORD POWER LEAD TO ACN (NEUTRAL) CONNECTOR
* FOR USE ON ALL WARING CB15 SERIES ONE GALLON 3 SPEED BLENDERS WITH PULSE FEATURE PRODUCED AFTER AUGUST 20, 2013
* SIMPLE 5 WIRE LEAD CONNECTION AS FOLLOWS;
FROM 08/20/2013 TO 11/10/2017 PRODUCTION SPEED CONTROL RIBBON CONNECTOR TO C10 CONNECTOR, FROM LEFT TO RIGHT GREEN, RED, BLACK
BLACK MOTOR LEAD TO M+ CONNECTOR
BLUE MOTOR LEAD TO M- CONNECTOR
BROWN CORD POWER LEAD TO ACL (LINE) CONNECTOR
BLUE CORD POWER LEAD TO ACN (NEUTRAL) CONNECTOR
FROM POST 11/10/2017 PRODUCTION ON SPEED CONTROL RIBBON CONNECTOR TO C10 CONNECTOR, FROM LEFT TO RIGHT GREEN, RED, BLACK
BLACK MOTOR LEAD TO M+ CONNECTOR
RED MOTOR LEAD TO M- CONNECTOR
BROWN CORD POWER LEAD TO ACL (LINE) CONNECTOR
BLUE CORD POWER LEAD TO ACN (NEUTRAL) CONNECTOR
